Wireless Microphone System 4-Channel UHF LCD Display White

DETAILS

Features:

• UHF Band Receiver System
• Quad Frequency 4-Channel Design (Channel 1, 2, 3, 4) Addressable Frequency
• Broad Frequency Response Range & Low Distortion
• High Signal/Noise Ratio Performance
• RF Signal Indicator on LCD Screen
• Radio Frequency Display on LCD Screen
• 1 XLR Output Connector Jacks (as only one receiver)
• Independent Channel Adjustable Frequency Controls
• Universal Portable Microphone System



Transmitter Technical Specs:

• Number of Channels: 16
• Oscillation Mode: DSP Chip Frequency Lock
• Stability: ¬±10ppm
• RF Power: 10dBm
• Distortion Degree: <0.5%
• Battery Type: 1.5V, 'AA' Alkaline Battery
• Battery Life: 4-8 Hours



Receiver Technical Specs:

• Use LCD Screen Display
• Oscillation Mode: DSP Chip Frequency Lock
• Stability: ¬±10ppm
• Receiving Sensitivity: -95-72 dBm
• Distortion Degree: <0.5%
• Signal to Noise Ratio: >90dB
• Audio Output: 300mv (Maximum)



What's in the Box:

• (4) Wireless Microphone
• (8) 'AA' Battery
• (1) USB to Micro USB Charging Cable
• (4) Plastic Microphone Anti-Drop Rubber Ring
• (4) Microphone Sponge
• (1) Microphone Receiver
• (1) 3.5mm Jack Audio Input Connector
• (1) 18650mA Battery
• (1) Plastic Case
