QUESTIONS & ANSWERSAsk a Question
Does this have enough power to drive a passive subwoofer? For example, use channels 1 & 2 for satellites and 3 & 4 for subwoofer?
Yes, there is a setting on the amp to function as a subwoofer amp as well as a full range setting for full range speaker
I have the plmra430bt I installed in my boat in July 2021, Used it for the first time, ran great all day. Came home later day, tried to connect via iPhone with no luck. Can see Pyle in my Bluetooth list. The logo is on the top of the amp is illuminating. when i power on the amp (via remote power) i can hear and see a speaker pulse on way, pleas advise.
Try to disconnect all power cables and drain the amp for 15 minutes then reconnect all power cables. Power up the unit and reconnect BT
Where is the volume control
The unit does not have volume control. What it has is a Gain Level control. Volume is controlled by the head unit you are using in your car
Where is the remote power switch for this amp? Please let me know if this is a seperate item or it was included.
There is no power switch. The remote terminal is along with the power terminal this is connected to the Remote Trigger of the head unit. Or you can just simply place a jump wire from the remote terminal going to the +12 volts terminal.
it will not connect to bluetooth
Hi! If there are several Bluetooth devices connected to the unit, kindly disconnect it all first. Then, try to pair again your device, look for the bluetooth network name "Pyle Amp". Please note that the wireless audio range is up to 25'+ ft.
Hope this will helps!
I have the plmra430bt I installed in January in a Sandrail has never been in weather. I’ve got the main power hooked up direct to battery and have the remote switch hooked up to turn on /off. Worked great for about 1 month. Probably played it 15 times. One day the amplifier will not power up. Have checked all my connection but can not get the amp to power up.
Check if the RED and YELLOW wires are getting 12 volts supply.
Check if the fuse are good.
Check for wires that maybe grounding on metal that can cause short circuit.
Check if speakers have been over driven.
What is the RMS Wattage on this amp per channel
The RMS per channel on the PLMRA430BT is 250 Watt x 4 Power Output
I’m trying to connect you 400 watt marine amp to this unit to power another subwoofer, is this possible? And what would I need?
The unit PLMRA430BT already has a subwoofer output on the channel 3 and 4.
What gauge wire to power amp given distance is 15ft from power source
16gauge wire will be doable for the work.
