8-Ch. Elite Series Marine Amplifier PLMRA820

Product Description
Elite Series Waterproof Amplifier, Bridgeable 3000 Watt 8-Channel Amp

  • PREMIUM RCA INPUT: For an easier use of this hydra marine amplifier, it comes with premium RCA inputs. If your marine receiver lacks RCA output jacks, you can connect speaker output leads to the high-level inputs.
  • SHORT PROTECTION: Built with a heavy duty Aluminum Alloy heatsink, thermal overload speaker short protection and LED light indicator. These are to protect the amp and your vehicle's electrical system from short circuit conditions.
  • POWERFUL 3000 WATT: This amplifier is powerful with its 3000 WATT maximum and MOFSET power supply. Comes with dual adjustable input GAIN level controls of 10k Ohm speaker impedance.
  • MARINE GRADE: With its Marine rating of IP-01, it is waterproof ready. It’s constructed with gold-plated speaker output terminal connectors as well to combat corrosion with long term use.
Sku: PLMRA820
Vendor: Pyle
$251.99
View On Amazon
Maximum quantity available reached.

Features:
  • Bridgeable Audio Amplifier
  • Tri-Mode Configurable
  • 8-Channel Amp System
  • 2 Ohm Stereo Stable
  • MOSFET Power Supply
  • Marine Grade Construction
  • Waterproof Marine Rating IP-01
  • Hi/Lo Electronic Crossover Network
  • Adjustable Input GAIN Level Controls
  • RCA (L/R) Input Connector Jacks
  • Variable High Pass, Low Pass & Bass Boost Controls
  • Remote Bass Boost Controller Connector Jack
  • Silver-Plated Speaker Output Terminal Connectors
  • Anti-Thump Delay Circuitry
  • Power & Protection LED Indicators
  • Built-in Thermal, Overload & Speaker Short Protection
  • Heavy Duty Aluminum Alloy Heatsink
  • Remote Turn ON/OFF

    Technical Specs:
  • 6 x 100W + 2 x 250W RMS @ 4 Ohms
  • 6 x 250W + 2 x 500W MAX @ 4 Ohms
  • 6 x 175W + 1 x 400W RMS @ 2 Ohms
  • 6 x 350W + 1 x 800W MAX @ 2 Ohms
  • Amplifier Class: AB
  • Fuse Type: 80A
  • Frequency Response: 15 - 30kHz
  • Input Impedance: 10k Ohm
  • Input Sensitivity: 250mV
  • Variable Bass Boost: 0 +/- 18dB @ 60Hz
  • S/N Ratio: >95dB
  • T.H.D.: <0.04%
  • Power Supply: DC 12V
  • Dimensions (L x W x H): 19.6'' x 10.9'' x 2.7''
  • Extend Warranty Protection and Earn Rewards. Click HERE for Registration

    QUESTIONS & ANSWERS

    Ask a Question
    • I would like to connect 6 - 6.5" speakers and 1 - dual 4ohm 10" subwoofer. Can I use channels 7/8 together for the sub? What would be the power ratings in the configuration? 6 x 100 and then 2 x 100 totaling 200 for the sub?

      6 x 100W + 2 x 250W RMS @ 4 Ohms
